Saturday, June 12, 2021

World's southernmost ski resort



What might be the world's southernmost ski resort? Internet claims that the answer is Cerro Castor, outside Ushuaia, on the southern end of Argentina. But, that is actually NOT the right answer. Glaciar Martial, a small ski slope in the city of Ushuaia is actually south of Cerro Castor. But wait, even that is NOT right. There's an even smaller ski slope, Club Andino Ushuaia, south of Glaciar Martial. Or is there?

Cerro Castor (website, wikipediaskiresort.info page) is a great, large ski resort with slopes covering high alpine region to the east of Ushuaia. They have 29 km of slopes. The resort base is at S 54.723416 W 68.018205, and the southernmost slope point appears to be S 54.724527 W 68.008713 on the "Avutarda" trail. See the trail map.

Glaciar Martial (website, skiresort.info page) is a one-lift operation right in Ushuaia. They have 5 km of slopes and 190m vertical. Although the 5km seems a bit suspect, I remember them having just one slope, which the trail map also seems to confirm. Eyeing the slope from the satellite map it seems like a bit over 1km. The base is at S 54.798732 W 68.370889, which is also the southernmost point on the one slope it has.

When Tero and I did our big Argentinian ski tour, we visited both Cerro Castor and Glaciar Martial. When we were departing Ushuaia, on our way to the airport, we saw. a third ski slope on the mountains, Club Andiano. And were bummed!

Club Andiano Ushuaia (website, skiresort.info page) is even smaller than Glaciar Martial. Per skiresort.info they have only one 0.5 km slope and 190 m vertical. There's a sort of a trail map (maybe) here. The south end of lift track appears to be at S 54.812530 W 68.351065.

So the right answer is Club Andiano. THAT is the southermost ski resort or slope in the world! And I have not skied there, despite being in Ushuaia. Grr!

But, skiresort.info says "The ski resort has shut down and skiing is no longer possible". Hmm. So is it still open? The Club Andiano website does talk about this year, but... it is difficult to see evidence of them actually operating the alpine ski parts of their operation. All information about skiing classes seems to indicate Cerro Castor as the location. So what's the story?

Google maps pictures seem to indicate a ski slope next to the lift towers, but growing with trees. So maybe that's the conclusion, then? But it would sure be nice to know what the actual situation is. Does someone know? Any locals?

One could perhaps claim that Cerro Castor is the southernmost ski *resort* while Glaciar Martial is the southermost ski *slope* or local ski hill. And that Club Andiano *was* the southernmost ski slope but is no longer.

And Tero I have visited what appears to be currently the world's most southern ski hill. But at the time we visited it, we missed visiting the one that actually was the most southern one back then. Hmm. Well, if I ever get to go to Ushuaia again, I will make sure to climb the Club Andiano slope just for safety's sake :-)

Note: Obviously, there's skiing more south, all the way to the south pole. But there are no ski resorts, organized ski slopes, or ski lifts.

Pictures from Cerro Castor:









Pictures from Glaciar Martial:





Pictures from Ushuaia:






This article has also been published at TGR. Read the full Planetskier series at planetskier.net, or all blog articles from Blogspot or TGR. Photos, videos, and text (c) 2012 and 2021 by Jari Arkko and Tero Kivinen.

Friday, June 11, 2021

Solamäki tour

Kari Vierinen organizes nature appreciation walks in Siuntio, and he called me to join their walk to the Solamäki caves in Siuntio. It was a very nice experience, particularly with the new information about paintings in the cave that Kari was able to tell us about.

I was here to look at the cave, and meet others interested in the cave. But the Solamäki caves were one of the early cave maps that I had drawn, and the map needed an update. I was able to take a few measurements to update the map. And, armed with the new iPhone LiDAR, I also recorded a 3D model of the cave.

The caves are in coordinates N 60.28260 E 24.29597. There's actually a main cave, a side crack cave few meters to the side of the main cave lower entrance, and few smaller caves around the cliff. There's also a separate boulder cave that we discovered on this trip, and previously discovered small shelter cave and boulder cave in the forest at the top of the cliff.

Kari introduced us to the cave paintings in the cave. They are reportedly 100-200 years old, not ancient, but still very interesting! I had not seen them before:

The new map can be seen below, or in more high resolution in PDF here.

The 3D model of the main cave be downloaded here or rotated on your browser screen here. Below is a snapshot of how the model looks like (as a static picture).

The 3D model of the arcing crack cave be downloaded here or rotated on your browser screen here. Below is a snapshot of how the model looks like.

We also passed by a boulder cave, maybe 1.5 meters long, downhill from main cave in coordinates E 60.283138 E 24.295684.



Main cave entrance:

This article has also been published at TGR. Read more urban exploration stories from theurbanexplorer.net, and other underground stories from planetcaver.net. Read the full Planetskier series at planetskier.net, or all blog articles from Blogspot or TGR. Photos and text (c) 2021 by Jari Arkko. All rights reserved.

Sunday, June 6, 2021

June and the Grani hill is still going strong



It is June 6th, and Grani ski hill *still* has snow! Thanks go to the ski hill maintenance team who made and piled a lot of snow during the season.

This is definitely the most snow there ever has been in June, but quite possible the only time the snow has lasted until June. Not sure...  need to check that.




This article has also been published at TGR. Read the full Planetskier series at planetskier.net, or all blog articles from Blogspot or TGR. Photos, videos, and text (c) 2021 by Jari Arkko.

Sunday, May 30, 2021

Saunalahti hole



I was originally going to explore bigger caves in Nuuksio this weekend with Jarmo, but I forgot that I was dogsitting Olli's dog while they were moving. I couldn't take the dog to long hike and boulder fields, so ended up doing nice walks in the seafront during the weekend. One of those walks to go see the Saunalahti hole, a small crystallization hole in an otherwise solid ground rock.

I also recorded a 3D model of the cave, available here in GLB format and here in STL format. Or click this to rotate the model on your screen :-)

I've been here before as well, with Janne, some years ago.


Saunalahti is also a wonderful place to walk around. Just look at the forest and sea views, or the random sheep that I run into on the walk:

Read more urban exploration stories from theurbanexplorer.net, and other underground stories from planetcaver.net. Read the full Planetskier series at planetskier.net, or all blog articles from Blogspot or TGR. Photos and text (c) 2021 by Jari Arkko. All rights reserved.


Sunday, May 23, 2021

Herttoniemi boulder underside



While visiting (again) the secret Margarine factory tunnel, I  came across a small boulder cavelet in Herttoniemi.

Not big, maybe 2x2 meters, but counts as a cavelet, i.e., a mini cave. Or in other words, it counts as a cave for people who are starved of real caves, like we are in Finland.

Read more urban exploration stories from theurbanexplorer.net, and other underground stories from planetcaver.net. Read the full Planetskier series at planetskier.net, or all blog articles from Blogspot or TGR. Photos and text (c) 2021 by Jari Arkko. All rights reserved. Thanks for Helene and Touko for accompanying me to the cave!

Airplane meal... on the ground!

I've been missing this... or have I?

More flying stories at Planetflier.com. Photos and stories (c) 2020 by Jari Arkko. All rights reserved.

Sunday, May 16, 2021

Avalanche transceivers as cave location devices?



A while ago, Bo Lenander asked a question in the Swedish Caver's Association if avalanche transceivers could be used as cave location beacons. As I have such transceivers, I started looking into this...

Background

Radios have been used in caving and cave research for both communication and determining locations. Communication is needed for safety and other reasons. For instance, emergency situations, exploration progress and estimated return times to be communicated, etc.

Pinpointing locations is also a safety matter. But accurate measurement of locations is also useful for constructing cave maps. Underground map construction relies on sequences of measurements where small errors may accumulate over long distances, and being able to pinpoint a particular place in the cave allows parts of the map to be fixed with respect to their ground location and GPS.

Cave radios typically operate in low frequency areas, as higher frequencies are more easily absorbed by rock. For instance, the cave radios reported in [Jones] operate at 88 Khz and 10W, and System Nicola Mk2 radios [Naylor] at 86.95 Khz (also 455 Khz) and 3W. The devices fall in the category of short range communication [ETSI 300 330], but the radios can pass through even hundreds of meters of rock.

Avalanche transceivers are emergency devices operating at the 457 Khz frequency at 0.1W [ETSI 300 718] [Hereford]. The frequency corresponds to 656 meter wave length, and space 456.9-457.1 has been allocated for emergency location devices in [ERC 70-03]. A transmitting device sends a signal once per second, with the signal lasting at least 70ms and break between signals being at least 400ms.

Contrary to cave radios, avalanche transceivers are consumer devices, are mass manufactured, and come with protective enclosures needed to protect them for water and humidity. These devices appear to have a useful range in open air somewhere between 50 and 100 meters. Given that the devices operate with a much longer wavelength than their range and they use small antennas, their operation is largely in the near field and based on magnetic fields.

The basic avalanche rescue process involves a finding the strongest signal strength on the terrain plane, and then using metal probes for the final and most accurate pinpointing of a buried victim. Older devices simply provide an audio signal, but newer devices may provide some additional distance or direction assistance to help the transceiver search.

The question posed in this article is: Can avalanche transceivers be used for communication to and from caves, or localization functions? Yes or no? And if yes, at what limitations?

Other work

It has been difficult to find articles about the use of avalanche transceivers in caves, even though there are some articles.

Frank Reid tested unmodified and modified avalanche beacons in 1988 [Reid]. At this time, the avalanche beacons used an earlier frequency, 2275 Khz instead of the current 457 Khz. Reid found that free space range in those beacons was in practice around 30 meters, but with different antenna arrangements this could be made up to 100 meters. Tests in Buckner cave were able to find a transmitter 17 meters underground.

Lou Dawson reported that in the history of making the first avalanche beacons in the 1960s, some of them were actually used for sewer and cave passage location tracking by the city of Lockport [Dawson].

Atanas Rusev recently reported "how he has used them for finding new entrances into large cave systems, and to identify dig locations for joining two caves", but unfortunately we have been unable to find a copy of the article [Rusev].

Absorption of electromagnetic transmissions in materials is of course in general well understood, see, e.g., [ITU] for a good summary of the relevant physics and equations. The equations are, of course, highly dependent on the nature of the materials, e.g., their permittivity and conductivity.

Unfortunately, while there are a lot of sources listing parameters related to absorption in the literature,  most of them do so only for construction materials [NIST] [Ofcom] [ITU] [Agilent] [RFCafe] [Achammer], not natural materials like different types of rock. Most literature also focuses on shorter wave lengths that are used for common communication (GSM, LTE, etc.) William Pullen's report from 1953 provides some information, such as, "attenuation measurements made with transmission lines antennas buried in soil indicated 7.5 db at 350 Khz to 11.7 db in 600 Khz" [Pullen], but it isn't clear if these numbers are useful for our case.

Tunnel experiment 1

A man-made tunnel in granite bedrock in Kauniainen was used for an initial test. In the very first test we used a 6 meters wide tunnel that goes in a circle, horizontally, around an area of rock. The rock area in the center of the circle is roughly 35 meters in diameter. A transceiver in transmitting mode was placed on the rock wall in one part of the circle, and then we attempted to measure the signal with a transceiver in reception mode as we passed through the circle alongside the center wall. See Figure 1 below.

Measurements with the devices are difficult, as no absolute reception level is indicated, exact accuracy of a given device being unknown, and the method at which the signal is presented in the software-driven user interface is also unknown. Nevertheless, the presence of a signal can be detected, and some indication of the strength and direction of the signal is given in the user interface. False positive signal reception is possible but in the author's experience relatively rare and random.

The result from the first experiment in the tunnels is that strong signal was received in areas close to the transmitter (< 15m), moderate strength was seen beyond that but very weak/spurious signal was received behind the center rock. But it was still received. Unfortunately, not much can be determined from this experiment for any of the measured distances. This is because (a) false positive signals can not be entirely ruled out and most importantly, (b) wave guide propagation along the tunnels and around corners cannot be ruled out.

Tunnel experiment 2

The second experiment in the tunnels provided more information. This experiment was performed in the entrance tunnel, a tunnel that descends gradually while the ground above rises. One test was made 25 meters from the tunnel entrance, and another 55 meters from the tunnel entrance. See Figure 2 below. Tunnel height was 5 meters. Distances and gradients were measured using a DistoX laser and digital inclinometer device [DistoX].  Rock depths have been calculated based on this input and are approximate.

The tunnel exit might allow the transmissions to escape. However, no reception was determined at or above the exit, or on the way towards areas where reception was determined, so we believe that alternate signal path and reflections were unlikely.

The result is that a moderate/weak signal was clearly detected at the 25 meter location, above ground and with approximately 8.4 meters of rock in between to the transmitter. This signal was confined to about a 10-meter wide circle in the ground and was not present elsewhere. At the 55 meter location (12.4 meters of rock and altogether 17.4 meters away) a very weak signal was detected. Again, it cannot be shown that this was not a false positive signal, but while the signal was not continuously detectable, it was only detectable in a given area, so the current hypothesis is that it was an actual reception of the transmission from underground.

Cave experiment

We travelled to Finland's largest karst cave, Torhola in Lohja [Torhola]. This cave spans horizontally 30 meters and vertically 11 meters, but has over 100 meters of cave passage in a complex multi-level structure. The bottom parts of the cave are far away from the entrance, both in in vertical and horizontal direction. Yet they are relatively close to surface, as the cave begins from the top of a hill, and descends downhill towards a lake.

On a previous visit, we had looked at a small side passage at the bottom part of the cave. This passage might be at near the surface. On that visit, hitting rocks with rocks could be heard on the surface, but pinpointing the location where the sound was coming from was difficult.

On the experiment visit, we placed a transmitter beacon at the entrance of this side passage (the passage itself was flooded at the time). See picture below.

Back on the surface, a search was made to find the lowest display reading (i.e., nearest to the transmitter) at the xy-plane. This search was quite easy, as the indicated strength/distance numbers changed quickly and consistently from all directions towards the minimum. See the picture:

The best location for signal reception was roughly in the middle of this picture, in the ground few tens of centimetres from the bottom of the rock step:

The lowest readings, in the range of 11-17 correspond to being closer than 2 meters, when I've used the device for measuring in free space.

Conclusions

It clearly is not possible to use avalanche transceivers for long-range communication, given the limited power and used frequency. In fact, without modification these devices would not be usable for any communication, as they have no means to carry any user-settable signal (although this may be changing with supplementary vitals data link [W-Link]).

However, perhaps surprisingly they do appear to be usable as localisation device for caves at small depths (< 15m). The author has experimented with this in Finnish caves that are typically small and may never exceed that limit.

Further experiments would be useful. We did not test the effect of antenna orientation, for instance. There seems to be also a big difference between different beacon products, and the ability of their user interface to provide information also differs.

Experiments in larger caves would also be very useful. For instance, the Swedish Lummelunda cave is relatively close to the surface, despite having several kilometers of tunnels. Lummelunda's depth (~20m) may exceed the performance of the avalanche beacons, however, even if the environment may be easier with less concrete, electrical wiring, and human settlements than in the tunnel in our experiment.

Further work would be useful to calculate the theoretical limits of 457 Khz communication through rock. Measurements relating to different rock types would also be useful.

Finally, it is still unclear if the results are relevant. Clearly, purpose-built cave radios and and localization equipment is far superior. However, it appears that in very limited cases readily available consumer devices may also be used. The author was able to pinpoint a location of a recently discovered tunnel part in the Torhola cave using the avalanche transceivers.

Acknowledgments

These experiments were inspired by Bo Lenander's questions [Lenander] -- thank you. Thanks to the city of Kauniainen and Nina and Markku for access to the tunnels for my measurements, for Ralf, Per, Tor, and Jarmo accompanying me on the first Torhola cave tour, for Helene and Touko for accompanying me on the second tour, and Jarmo and Tero for discussions in this problem space.

References

[Achammer] Achammer, T. and  Denoth, A., "Snow dielectric properties: from DC to microwave X-band". Ann. Glaciol. 19, 92–962, 1994.

[Agilent] Agilent, "Basics of Measuring the Dielectric Properties of Materials". Application Note.

[Dawson] Lou Dawson, "SKADI - First avalanche rescue transceiver beacon". August 2013.

[DistoX] Beat Heeb, "Paperless cave surveying".

[ERC 70-0] ERC, "Relating to the use of Short Range Devices (SRD)". ERC recommendation 70-03.

[ETSI 300 330] ETSI, "Short Range Devices (SRD); Radio equipment in the frequency range 9 kHz to 25 MHz and inductive loop systems in the frequency range 9 kHz to 30 MHz; Harmonised Standard covering the essential requirements of article 3.2 of the Directive 2014/53/EU".

[ETSI 300 718] ETSI, "Avalanche Beacons operating at 457 kHz; Transmitter-receiver systems; Part 1: Harmonised Standard for access to radio spectrum".

[Hereford] John Hereford and Bruce Edgerly, "457 KHz Electromagnetism and the future of avalanche transceivers".

[ITU] ITU, "Effects of building materials and structures on radiowave propagation above about 100 MHz". Recommendation ITU-R P.2040-1, July 2015.

[Jones] Herman Jones, "The cave radio".

[Lenander] Bo Lenander, "Enkel grottpejl??".

[Torhola], Suomen Luolaseura. "Torholan luola". The Torhola cave entry in the Finnish Caving Association's database.

[Naylor] Graham Naylor, "System Nicola Mk2".

[NIST] William C. Stone, "Electromagnetic Signal Attenuation in Construction Materials". NIST, October  1997.

[Pullen] M. William Pullen, "Geologic Aspects of Radiowave Transmission", Report of Investigations no. 162, State Geological Survey, pp 19-20, Illinois, 1953.

[Ofcom] Richard Rudd, Ken Craig, Martin Ganley, and Richard Hartless, "Building Materials and Propagation". Final report, Ofcom. September, 2014.

[Reid] Frank Reid, "The Easiest Cave Radio: Extending The Range of Avalanche Beacons". Volume 3 #2 June 1988.

[RFCafe] RFCafe, "Dieletric Constant, Strength & Loss Tangent".

[Rusev] Atanas Rusev, "Radiolocation, Using Avalanche Beacons in Cave Exploration". September 2019.

[Tsuchiya] Toshio Tsuchiya, "Absorption (A) and Transmission Loss (TL) in Seawater".

[W-Link] Wikipedia, "W-Link".

This article has also been published at TGR. Read more urban exploration stories from theurbanexplorer.net, and other underground stories from planetcaver.net. Read the full Planetskier series at planetskier.net, or all blog articles from Blogsspot or TGR. Photos and text (c) 2021 by Jari Arkko. All rights reserved.
